DA-6000SS
Innovative Features
of the New Soundproof DA-6000SS Diesel Generator Brush less generator with
built-in voltage compensating windings an initial voltage winding eliminates
the needs for an automatic voltage regulator or initial voltage builder, for a
stable power source. Exceptionally quite operation accomplished through the use
of state of the art sound proofing technology. Newly designed exciter system
(Japan Patent Nos. 1843374 & 1998273 and Utility model No. 2025607)
improves motor starting capability for electrical motors. The large side doors
allow easy access for daily maintenance. Automatic warning and shut-off device
for low oil pressure, high water temperature and insufficient charging.
Equipped with circuit breaker to protect alternator from over-current. Air
bleeding can be accomplished merely by cranking. Registered as an
emission-improved construction machine complying with both current Japanese and
U.S. EPA and CARB regulations. Compact and light weight design owning to
2-poles alternator and well matched engine. A highly efficient alternator and
fuel-efficient engine enable continuous operation for up to 10 hours at 100%
load. Earth leakage circuit breaker, AC ammeter, frequency meter, automatic
slowdown and remote control unit (RC70) are optional. SPECIFICATION TABLE
Specifications Model DA-6000SS Alternator Frequency (Hz) 50 60 Rated Output
(kVA) 5.5 6.0 Rated Voltage (V) Double Voltage System 100/200,110/220,115/230
100/200,110/220,115/230,120/240 Power Factor 1.0 No. of Phases Single Phase, 4-Wire
Exciting System Revolving-Field, Self-Exciting New Brushless Diesel Engine
Manufacturer & Model KUBOTA Z482 Type 4-Cycle, Water-Cooled, Swirl
Chambered No. of Cylinders 2 Bore x Stroke (mm) 67x68 Displacement (L) 0.479
Rated Output (kW/min) 6.5/3000 7.7/3600 Fuel ASTM No. 2 Diesel Fuel or Equivalent Fuel Tank
Capacity (L) 25 Fuel Consumption (L/h)* 2.1 2.6 Starting System Electric
Battery 12V 35 Ah Dimension & Weight Length (mm) 1140 Width (mm) 650 Height (mm)
795 Dry Weight (kg) 239 Sound Level 7m/dB (A) 3000/3600 min 61
