Elemax Gen

•

  SH11D

  FREQUENCY: 50 HZ RATED OUTPUT: 8.0KW MAX OUTPUT :8.8KW RATED VOLTAGE 220V RATED CURRENT: 36.4 A PHASE/WIRES: 1PH /2 WIRE TYPE: 2-POLE FIELD ROTATING TYPE WITH AVR POWER FACTOR :1.0 ENGINE: KUBOTA D722 TYPE: VERTICAL WATER COOLED A CYCLE DIESEL ENGINE NO OF CYLINDER :3 CONTINUOUS RATED OUTPUT:10.3 KW ENGINE SPEED :3000 RPM ELECTRIC STARTER DIMENSIONS: LX W X H MM =1281X618 X 698 SOUND LEVEL: 68

•

  SHX1000

  Frequency (Hz) 50 60 Engine Speed (rpm) 5800/4100(Power Mode/Silent Mode) Waveform Square-Wave AC Output Maximum Power (W) 1000 Rated Power (W) 900 Rated Voltage (V) 220 230 220 120 DC Output Only for Charging 12V Automotive Batteries. Maximum Charging Output = 8.3/4.2A (Power Mode/Silent Mode) Insulation Class B Engine Maker HONDA Model GXH50 Type Air Cooled OHV 4-stroke Gasoline Displacement (CC) 49.4 Others L X W X H (mm) 465 X 265 X 380 Dry Weight (kg) 13.6 14.0 13.6 13.6 Fuel Tank Capacity (liters) 3.8 Sound Level [dB(A)/7m] 58(1/2 load) (dB Lwa ) 89(3/4 load) Pilot Lamp LED Power Indicator LED Oil Alert System YES Engine Stop Interlocking with Fuel Cock AC Output Plug Socket X 1 Plug Socket X 2 Protective Device Control Circuit DC Output Terminal Protective Device Thermal Type Circuit Breaker

•

  SHX2000

  Frequency (Hz) 50 60 Engine Speed (rpm) 4500 Waveform Square-Wave AC Output Maximum Power (W) 1900 1700 1900 Rated Power (W) 1500 Rated Voltage (V) 220 230 220 120 DC Output Only for Charging 12V Automotive Batteries. Maximum charging output = 8.3A Insulation Class B Engine Maker HONDA Model GX100 Type Air Cooled OHC 4-stroke Gasoline Displacement (CC) 98 Others L X W X H (mm) 560 X 340 X 415 Dry Weight (kg) 21.0 22.0 21.0 21.0 Fuel Tank Capacity (liters) 7.7 Sound Level [dB(A)/7m] 63(1/2 load) (dB Lwa ) 93(3/4 load) Pilot Lamp LED Power Indicator LED Oil Alert System YES Engine Stop Rocker Switch AC Output Plug Socket X 2 Protective Device Control Circuit DC Output Terminal Protective Device Thermal Type Circuit Breaker
